REED Instruments R9000 HD PIPE VIDEO INSPECTION SYSTEM

(No reviews yet) Write a Review

$2,095.00

Brand

SKU:

R9000

Description

Features

Cost effective portable inspection camera designed to deliver quality video inspection in a wide range of applications including: sewers, building ducts/piping, wells, and power plants
System includes camera head, cable reel, battery pack and DVR
Camera head contains 12 white LED lights, a flexible spring coiled joint to navigate corners, a scratch-resistant sapphire lens cover and a stainless steel housing that allows the camera to withstand various hits
High resolution CCD chip is designed to capture bright, crisp, colour video of the inspection area
7" TFT LCD display presents a live crisp colour image at your fingertips
Cable reel is mounted and rotatable in the case, therefore the fibreglass rod cable can be pushed in and out without the need to hold the reel
Sun visor is included to act as a sun shield for outdoor inspections

Included

Application

Sensor	1/3" Sony CCD
TV-Line	420 TV-Line
View Angle	140°
Focus Distance	20cm (approx.)
Depth-of-View	100cm (approx.)
Camera Size	ø23mm x 45mm
Camera Length	120mm
Lighting	Built-in12 white LED
Waterproof	20m water (camera fixed on cable)
Power Supply	12VDC
Cable Diameter	ø5.2mm
Cable Length	20m
Screen	7" 16:9 high-definition colour LCD
Resolution	800 x 480 RGB
Video Resolution	PAL 720 x 576 25 FPS Max NTSC 720 x 488 30 FPS Max
Photograph	720 x 480/720 x 576
Output	TV and Audio
External Memory	Supports SD memory card up to 32GB
Data Output	USB 2.0 to PC
Play Back	Video, Photo and Audio
Power Supply	DC 6~12V input
Power Input	DC 9~12V
Battery Capacity	DC 7.4V 6600mAh Li-ion battery
Power Output	DC 6~12V & DC 5V
Running Time	7 hour (Record), 9 hour (Play Back)
Charge Time	8 hour
