Santronics Low AC Locator # 3215

$21.95 $17.39
(You save $4.56)
SKU:
# 3215
Brand:
Current Stock:
Out of stock

Out of Stock

Product Description

These AC/DC Voltage Detectors from Santronics are ideal for just about any application. Simply touch the tic tracer's tip to a terminal strip, outlet, or supply cord, and when the tip glows red, you know that voltage is present. Their compact design makes them easy to transport and keeps them readily available for use on a jobsite. Each tic tester gives you visual or audio indications of power detection, and needs no contact with conductors to be activated.

  • Compact “pen-sized” design for easy transport and accessibility
  • Constructed of non-conductive polycarbonate for additional safety
  • Covered by one or more of the following patents 6,828,767 & 5,103,165
  • UL 1436
  • Made in the USA

Ideal for use in:

  • Service, maintenance
  • Automotive
  • Electricians
  • Telecommunications
  • Aviation Trucks/RV’s
  • Marine
  • Industrial Controls
  • Office Equipment



[custom1]

Cable Certification n/a
Outer Surface Non-conductive body, probe and cap composed of injected molded high-impact nonflammablepolycarbonate, with a dielectric of 220 Volts AC potential at 60 Hertz
Operating Voltage 24-90 Volts AC
Batteries
Operating Temperature -40° C to +55° C
Circuit Board Surface mounted components on FR-4 substrate
Light Source One high-intensitySMD LEDfor maximum illumination
Weight 40.6 grams with batteries
Dimensions 5.75” length; .75” in diameter
Breakdown Voltage 4000+ Volts AC
Test Lead Wire n/a
Tip Material n/a
Interior Conductor Strip Brass strip approximately 4.75” in length
Operating Principle This instrument senses the electrical field produced by AC voltage through insulation, without touching the conductor. A constant bright red glow will indicate the presence of AC voltage.

[/custom1]

[custom2]

pdf-icon.pngDatasheet
