Winter TY52200R WinSMART TY52 TEMPERATURE TRANSMITTER, MODBUS RS485 OUTPUT
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winter TY52200R WinSMART TY52 TEMPERATURE TRANSMITTER, MODBUS RS485 OUTPUT
$1,802.01
- Brand
- U.S. Winter instruments
- SKU:
- TY52200R
- UPC:
- 628311321043
- Availability:
- In Stock
Description
Winters, TY52200R, WinSMART? TY52 SMART Explosion Proof Temperature Transmitter, Modbus RS485 Output, 200mm (8") Insertion Length
Features:
- Integrated temperature transmitter with ASIC signalling transmitter
- Explosion proof smart temperature transmitter for hazardous locations
- -50 to 400?C (-58/752?F ) measure range
- 0.5% accuracy
- Simple to operate 3-push button control
- Re-zero function for safe field calibration
- 10:1 rangeability allows for installation in any application
Applications:
- TY52 can be utilized and installed anywhere where temperature measurement is required. From Oil & Gas installations to Power Generation, this product has a rugged design and is equipped with the communication protocols to meet all your day to day requirements
Specification
| Insertion Length | 200mm (8") |
| Output Signal | Modbus, 4-wire / V = 5/9-30 Vdc |
| Sensor Type | PT100 RTD |
| Measuring Range | -50 to 400?C (-58/752?F ) |
| LCDDisplay | LCD display (standard) |
| Accuracy | 0.5% accuracy |
| Stability | 0.05% or 0.1?C / year |
| Temperature Range |
|
| Working Humidity | 0-95% |
| Pressure Connection | 1/2? NPT |
| Housing | Rugged die-cast aluminum housing, painted blue |
| Wetted Parts | 316 SS, 304 SS |
| Power Consumption | </- 500 mW at 24 VDC, 20.8 mA |
| Vibration | 4g, 2?100Hz According to IEC 60068-2-6 |
| Temperature Units | Celsius (?C), Fahrenheit (?F) |
| Protection Class | EMI, ESD, RFI, reverse polarity protected |
| Approvals | Intertek, for USA & Canada - Class I, Division 2, Groups A, B, C & D, T6, -40?C to 60?C |
| Protection Class | IP67 |
