Winters LOW PRESSURE 4" 0-15" H20 VAC 1/4" BRASS PLP310V
$268.70
- Brand
- U.S. Winter instruments
- SKU:
- PLP310V
- UPC:
- 6.28311E+11
Features:
- Suitable for measuring gaseous media both corrosive and non-corrosive
- Used to measure natural gas pressure as well air flow indication and leak detection
- Vacuum pumps, air compressors, air filters, gas burners, vacuum ovens, suction regulators and respirators
- Highly accurate reading of low pressures
- Brass or stainless steel wetted parts
- Overpressure protection on some models (OP)
- ASME B40.100 compliant
- CRN registered
Dial | 4" (100mm) |
Case | Steel |
Lens | Polycarbonate |
Socket | Brass |
Connection | 1/4" Bottom |
Diaphragm Element | AISI 316 SS |
Pointer | Aluminum, anodized black |
Enclosure Rating | IP52 |
Movement | AISI 316 SS |
