REED SD-8205-NIST Description

This SD series datalogging vibration meter measures velocity and acceleration to determine vibration levels in machinery. The SD-8205 meets ISO1954 standards and features RMS, Peak hold, and Max/Min functions. Using a SD card (max 16Gb), a user can select a desired sampling rate and quickly generate an Excel file on a SD card without the use of software. Optional accessories include a tripod and AC adapter for continuous long-term monitoring. Optional PC software also allows a user to track live measurements.

This product includes a Traceable Certificate with full Data and Uncertainties.

Features

Measures velocity and acceleration to determine vibration level
User selectable unit of measure (metric or imperial)
RMS, Peak hold, Data hold and Max/Min functions
10Hz to 1kHz frequency range
Basic accuracy of +/-5%
Real-time datalogger with integral SD memory card
User selectable sampling rate from 1 to 3600 seconds
Large, easy-to-read backlit LCD display
Optional PC software features live tracking via USB connection
Tripod mount for long-term monitoring
Meets ISO1954 standards
Low battery indicator and auto shut off

REED SD-8205 Specifications

Acceleration
Measuring Range	0.5 to 199.9 m/s² 0.05 to 20.39 g 2 to 656ft/s²
Accuracy	±(5% + 2 dgt)
Resolution	0.1m/s² 0.01 g 1 ft/s²
Velocity
Measuring Range	0.5 to 199.9 mm/s 0.05 to 19.99 cm/s 0.02 to 7.87 in/s
Accuracy	±(5% + 2 dgt)
Resolution	0.1 mm/s 0.01 cm/s 0.01 in/s
General Specifications
Response Time	1 sec
Frequency Range	10Hz - 1KHz
Display	4-digit LCD
Backlit Display	Yes
RMS, Peak and Max Hold Measurements	Yes
Data Hold	Yes
Min	Yes
Max	Yes
Zero Adjustment	Yes
Datalogging Capabilities	Yes
Real-Time Clock and Date Stamp	Yes
Selectable Sampling Rate	Yes (1, 2, 5, 10, 30, 60, 120, 300, 600, 1800, 3600s)
External Memory	Yes, expandable up to 16Gb with SD card (optional)
Auto Shut-off	Yes (after 10 mins/off)
Kick Stand	Yes
Tripod Mountable	Yes
Low Battery Indicator	Yes
Probe Cable Length	47.2" (1.2m)
Power Supply	6 x AA batteries or AC Adapter (optional)
Output	Yes
PC Connectivity	USB Cable (optional)
Software	SW-U801-WIN Software (optional)
Software OS Compatibility	Windows XP / Vista / 7
Product Certifications	CE
Operating Temperature	0 to 122°F (0 to 50°C)
Storage Temperature	14 to 140°F (-10 to 60°C)
Operating Humidity Range	10-85%
Dimensions	Instrument: 9.7 x 2.7 x 1.8" (203 x 76 x 38 mm) Probe: 1.5 x 0.6" (37 x 16 mm)
Weight	Instrument: 17.3oz (515g) Probe: 3.5oz (99g)
