UEI DT304 QUAD INPUT LOGGING THERMOMETER

UEI DT304 QUAD INPUT LOGGING THERMOMETER

(No reviews yet) Write a Review

$203.96

Brand: UEI test instruments
SKU:: DT304
UPC:: 53533505634

Current Stock:

Quantity:

Adding to cart… The item has been added

Description
0 Reviews

Description

UEi Quad Input Digital Logging Thermometer DT304 Apollo IV

Includes:

4 K type probes with lead wraps
2 AAA batteries
Quick Start Guide
Owners Manual

Features:

Quad Thermocouple input
Differential T1-T2 and T3-T4
Temp range -346° to +2192°F (J)
Temp range -328° to +2498°F (K)
Data logging
9,999 Memory positions
USB interface (software included)
Thermocouple temperature offset
MIN, MAX, AVG & Hold
Probe Storage
Accepts J, K, T and E type probes
5 year limited warranty

Safety Compliance:

IP67
Water submersion (3' for 30 min.)
High pressure dust resistance (max depression of 20 mbar for 8 hours)
CAT 1 Overvoltage
CE Certified

Specification

Measurement Range	J-Type: -346° to +2192°F (-210° to +1200°C) K-Type: -328° to +2498°F (-200° to +1370°C) T-Type: -418° to +752°F (-250° to +400°C) E-Type: -238° to +1832°F (-150° to +1000°C)
Display Resolution	0.1°F/°C < 1000° 1.0°F/°C > 1000°
Accuracy	J,K,T,and E-Type; ±[0.1% +1.0°F (0.5°C)] [Below -148°F (-100°C): add 0.2% of reading for J,K,and E-Type; and 0.1% of reading for T-Type]
Temperature Coefficient	0.01% of reading 0.1°F per °F(+0.05°C per °C) for <+64°F (+18°C) or +82°F (+28°C) [Below -148°F (-100°C): add 0.05% of reading for J,K,and E-type; and 0.1% of reading for T-type]
Real Time Clock Tolerance	About 1 second per day
Maximum Differential Common Mode Voltage	1V (maximum voltage difference between any pair of inputs)
Temperature Scale	ITS-90 (International Temperature Scale of 1990)
Applicable Standards	N.I.S.T. Monograph 175 revised to ITS-90
Dimension	7.20" (H) x 3.70" (W) x 1.70" (D)
Weight	Approx. 16.2 oz
Battery	2 x LR03 (AAA) type 1.5V
Certification	CE
Safety	IEC 1010-1 (2001),UL 3111-1 (6,1994), EN 61010-1 (2001),CSA C22.2 No. 1010.1 (1992)
CAT I	Over Voltage (Installation) CATEGORY I, Pollution Degree 2 per IEC 1010-1
Compliance	IEC 60529: IP67 (Ingress Protection rating) Water Immersion (3' up to 30 min) No ingress of dust (20mBar up to 8 hrs.)
Accuracy is specified for ambient temperatures between 64°F (18°C) and 82°F (28°C) for a period of 1 year. The above specifications do not include thermocouple error.
Calibration The Apollo Digital Thermometer's annual calibration, starting one year after purchase, is recommended to ensure that the thermometer performs to its accuracy specifications.
